8.18
A191
MAN
HW
D L2 S Z V
Ref.LH
Ref.RH
25 55,5 10x26 3
3
A191.025.012.10
■
A191.025.112.10
■
30 55,5 10x26 3
3
A191.030.012.10
■
A191.030.112.10
■
35 55,5 10x26 3
3
A191.035.012.10
■
A191.035.112.10
■
Dim.
Ref.
M5x10
705.103
M5x17
705.180
A192
MAN
HW
D L1 S Z V
Ref.
L1 = 90,0mm
15 90 10x60 2
2
A192.015.112.10
16 90 10x60 2
2
A192.016.112.10
18 90 10x60 2
2
A192.018.112.10
20 90 10x60 2
2
A192.020.112.10
22 90 10x60 2
2
A192.022.112.10
24 90 10x60 2
2
A192.024.112.10
25 90 10x60 2
2
A192.025.112.10
26 90 10x60 2
2
A192.026.112.10
28 90 10x60 2
2
A192.028.112.10
30 90 10x60 2
2
A192.030.112.10
32 90 10x60 2
2
A192.032.112.10
34 90 10X60 2
2
A192.034.112.10
35 90 10x60 2
2
A192.035.112.10
38 90 10x60 2
2
A192.038.112.10
40 90 10x50 2
2
A192.040.112.10
45 90 10x50 2
2
A192.045.112.10
50 90 10x50 2
2
A192.050.112.10
50 130 16x50 2
2
A192.050.130.16
55 140 16x50 2
2
A192.055.140.16
60 140 16x50 2
2
A192.060.140.16
Without center point, allowing boring depths close to the bottom-side laminate.
Sans centralisateur, permet des profondeurs de perçage près du fond, du côté revêtu.
Hinge boring bits
Mèches à façonner
■
■
While quantities last
- Jusqu’à épuisement du stock
Spare parts
- Pièces de rechange
Adjusting Screw
- Vis
Special adjusting Screw
- Vis spéciale de réglage
Long design
- Série longue
Hinge boring bits
Mèches à façonner
